Ultra Slim Fine Pitch P1.25 High Resolution, Video Wall Indoor Fixed LED Display Screen with Front Access

Basic Info

Model NO.	UHD
Tube Chip Color	Full Color
Display Function	Video Display
Pixel Configuration	1R,1G,1B
Display Type	LED Video Display
Application	Stage Performance, Advertising, Shopping Guide
Transport Package	Wooden Case
Origin	Shenzhen China
Production Capacity	7000m2/Month

Product Description

Ultra Slim Fine Pitch P1.25 High Resolution, Video Wall Indoor Fixed LED Display Screen with Front Access

Features:

1. Multi-screen splitting for displaying multiple messages and great videoconferencing

2. 16:9 aspect ratio,Stunning life-like image quality with 4K UHD resolution

3. lightweight die cast aluminum frames for strength

4. High gray scale, even at low brightness levels

5. Broadcast ready with high refresh rates

6. Fast lock system and magnetic modules for convenient installation and maintenance

Specification

	UHD-1.2	UHD-1.6	UHD-1.9
Physical Pitch	1.25mm	1.66mm	1.92mm
Pixel Configuration	SMD 0909	SMD1010	SMD1010
Pixel Density	640,000pixels/m²	360,000pixels/m²	10,000pixels/m²
Module Dimensions (W × H) (mm)	200 × 300	200 × 300	200 × 300
Panel Dimensions (mm)	400 × 300	400 × 300	400 × 300
NO .of Modules Per Panel (W × H)	2 × 1	2 × 1	2 × 1
Physical Resolution of Module (W × H)	160 × 240	120 × 180	208 × 156
Physical Resolution of Panel (W × H)	320 × 240	240 × 180	208 × 156
Panel Material	die-casting	die-casting	die-casting
Single Cabinet Weight	4.6 kg/panel	4.6 kg/panel	4.6 kg/panel
Servicing	Front / Back	Front / Back	Front / Back
IP Rating (Front/Rear)	IP 30	IP 30	IP 30



Our Service

1.Pre-sale service: Reply enquiries in 24 hours.Market research and forecast for customer.Provide unique and professional solutions based on customer's requirementData sheet and samples offer.Other services, such as special packing design, factory visiting and so on.2.In-sale service:Tracking report in producing.Quality test report for every order.Photos and videos as per customer's requirement.Free spare parts.3.After-sale service:Lifetime free maintenance and upgrade.Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.Customer satisfaction tracking report.Free technician training.Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.Special service for big project, such as stadium, exhibitions, squares and so on.



About us!

Shenzhen BAKO VISION Technology, started in Shenzhen in 2005, a world class manufacturer of technologically advanced LED displays, is SHENZHEN BAKO LTD holding end professional customers among domestic and overseas markets.

BAKO VISION contains of experienced team leaders and each of them has been working in LED display industry over 10 years. All of our R&D, Production, Sales, Technical Support depts….are running efficiently and smoothly by our great team work, moreover, delivering qualified product and offering timely pre-after service are also assured by BAKO VISION team.

Do not be hesitate to contact us if you have any quiry!

FAQ:

1. How to choose a proper led screen?

Then you need to clarify below:

A: It's for indoor or outdoor?For fixed or rental?

B: Where will you install this screen?

C: What is the distance between audients and screen?

2. Which control system should I choose?

There is both synchronous and asynchronous control system on the market of LED Display. For the big size led screen(usually more than 20sqm),it is suitable to use synchronous control system. For those displays which below

20sqm.It's up to you to use synchronous and asynchronous.
But the refresh rate of asynchronous control system is much lower than synchronous control system.

3.How about your package?
We usually pack in wooden boxes or flight case.It decide on your size and your needs.We respect your choice.
